General
1.Remote opening and closing
2.can monitor power, voltage, current , Power, temperature and other grid parameters.
3.It can protect the voltage, overloadcurrent,Parameters such as temperature and power limit can be
4.Protection value setting and function setting.
5.Can be operated remotely by remote APP or web terminal and parameter setting.
Technical Data
| Product or component type | TOQCB2L |
| Poles description | 2P |
| Control Type | Remote, Manual |
| Rated Current | 63A |
| Operating voltage Range | AC 145V – 295V |
| Over-voltage Threshold (V) | 245V – 295V |
| Under-voltage Threshold (V) | 145V – 220V |
| Terminal Temperature Threshold (℃) | -40℃ – 100 ℃ |
| Over-power Threshold (W) | 5W – 30000W |
| Rated Frequency | 50Hz/60Hz |
| Over-current Threshold (A) | 1A – 100A |
| Leakage Protection Threshold | 30mA-500mA |
| Operating system support | Android, iOS, HarmonyOS |
| Operating Language | Chinese, English, and Other |
| Voice Support | Amazon Alexa, Google Home |
| App Language | Follow the operating system language |
| Communication Protocol | WiFi 2.4Hz (default), ZigBee 3.0, 4G (customization) |
WiFi RCBO Function | Timing, Electricity monitoring, Over-current Protection, Short-circuit protection, Under-voltage protection, Over-voltage protection,Leakage protection |
