Description
Three-phase DIN rail voltmeters have gained popularity in industrial and commercial settings due to their space-efficient design, straightforward installation, and accurate voltage monitoring capabilities.
Compact Design: Three-phase DIN rail voltmeters boast a space-saving design, allowing for easy integration into control panels and other tight spaces within electrical installations.
Easy Installation: These voltmeters can be quickly and securely mounted on a standardized DIN rail system, simplifying the installation process and eliminating the need for additional hardware.
Accurate Voltage Monitoring: Three-phase DIN rail voltmeters provide precise voltage readings for three-phase electrical systems, enabling effective monitoring and control of power quality and overall system performance.
Three-phase DIN rail voltmeters are an efficient and compact solution for voltage monitoring in various industrial and commercial applications, including manufacturing plants, data centers, and power distribution networks. With their easy installation, accurate readings, and potential cost savings, three-phase DIN rail voltmeters are a valuable addition to any electrical system.
| Component Type | TOVME-3 |
| Currnet Type | AC |
| Rated Voltage | 230V (L1-N, L2-N, L3-N) |
| Voltage Range | 60-450V AC |
| Frequency | 45-65 Hz |
| Power Consumption | 3W |
| Accuracy | ±2% |
| Number of phases | Three-phase |
| Over-voltage withstand capability | +5% within 1 hour |
| Low voltage Alarm | L0 |
| High voltage Alarm | H1 |
| Meter Type | Digital |
| Display Digits | 3 |
| Boot Display | 888 (800ms) |
| Isolation | Complete isolation between channels |
| Mounting Type | DIN-Rail |
| Operating Temperature | 0℃ to +40℃ (32℉ to +104℉) |
| Storeage Temperature | -40℃ to +60℃ (-40℉ to +140℉) |
| Isolation | Complete isolation between channels |
| Degree of Protection: | IP20 |
