Description
TOMC3-63 AC 63A 2P Mini Circuit Breaker MCB protects the circuit from short circuit and overload.
It is suitable for lighting power distribution system or electric motor power distribution system.
TOMC3-63 AC 2P Mini Circuit Breaker MCB has beautiful appearance, small size, light weight, excellent performance and reliable performance.
High breaking capacity, rapid tripping, guide rail installation, high resistance for housing and components Combustible and impact resistant plastic, long service life.
2P Mini Circuit Breaker Special Tips
1. MCB is for non-professional operation by untrained personnel without maintenance.
2. B, C, D trip curve.
3. It is recommended to install special devices on the upstream line of the MCB, such as surge protection devices, lightning arresters, etc., to prevent potential surge voltage and current from appearing on the power input side.
4. Choose a suitable trip curve and install it correctly. When a fault occurs, the MCB will trip and cut off its protected circuit, thereby providing protection against electric shock.
5. In order to meet the above conditions and applications, MCB with “ON-OFF” indicating device is considered suitable for isolation function.
| Model Name | TOMC3-63/2/C63 |
| Pole No: | 2 |
| Rated voltage: | AC 110V 220V |
| Rated current(A): | 63 |
| Tripping curve: | C |
| Rated short-circuit capacity(lcn): | 3kA |
| Rated frequency: | 50/60Hz |
| Energy limiting class: | 3 |
| Rated impulse withstand voltage: | 6.2kV |
| Electro-mechanical endurance: | ≥ 6000 |
| Connection terminal: | Screw terminal / Pillar terminal with calmp |
| Connection capacity: | Rigid conductor up to 25mm² |
| Fastening torque: | 2.0Nm |
| Installation: | On symmetrical DIN rail 35mm / Panel mounting |
| Standards | IEC 60947-2, IEC 60898-1 , EN60898-1, AS/NES 60898.1 |
| IP degree of protection | IP40 for modular enclosure conforming to IEC 60529 |
| IP20 conforming to IEC 60529 | |
| Operating altitude | 2000 m |
| Ambient air temperature for operation | -35°C to +70°C |
| Type | Width 9 mm modules | ||||
| 2P | Rating (In) | B Curve | C Curve | D Curve | 4 |
 | 1A | TOMC3-63/1/B1 | TOMC3-63/1/C1 | TOMC3-63/1/D1 | |
| 3A | TOMC3-63/1/B3 | TOMC3-63/1/C3 | TOMC3-63/1/D3 | ||
| 5A | TOMC3-63/1/B5 | TOMC3-63/1/C5 | TOMC3-63/1/D5 | ||
| 6A | TOMC3-63/1/B6 | TOMC3-63/1/C6 | TOMC3-63/1/D6 | ||
| 10A | TOMC3-63/1/B10 | TOMC3-63/1/C10 | TOMC3-63/1/D10 | ||
| 16A | TOMC3-63/1/B16 | TOMC3-63/1/C16 | TOMC3-63/1/D16 | ||
| 20A | TOMC3-63/1/B20 | TOMC3-63/1/C20 | TOMC3-63/1/D20 | ||
| 25A | TOMC3-63/1/B25 | TOMC3-63/1/C25 | TOMC3-63/1/D25 | ||
| 32A | TOMC3-63/1/B32 | TOMC3-63/1/C32 | TOMC3-63/1/D32 | ||
| 40A | TOMC3-63/1/B40 | TOMC3-63/1/C40 | TOMC3-63/1/D40 | ||
| 50A | TOMC3-63/1/B50 | TOMC3-63/1/C50 | TOMC3-63/1/D50 | ||
| 63A | TOMC3-63/1/B63 | TOMC3-63/1/C63 | TOMC3-63/1/D63 | ||
