| Component Type | SPSD 2P 24V 1.5A |
| DC Output Voltage, Current | 24V 0~1.5A |
| Wave and Noise | 150mVp-p |
| Inlet Wire Stability | ±1% |
| Load Stability | ±1% |
| Efficiency | 87% |
| Adjustable Range for DC Voltage | ±10% |
| Input Voltage Range | 100~240VAC/120~370VDC 50/60Hz |
| Impact Current | Cold Start Current 25A/115VAC 45A/230VAC |
| Overload Protection | 105%~150% cut off the output, automatic recovery |
| Overvoltage Protection | 115%~140% rated output power Protection type: Hiccup mode, recovers automatically after fault condition is removed |
| Setup | 1500ms, 80ms |
| Rise | 230VAC 1500ms, 80ms |
| Hold Up Time | 115VAC(full load) |
| Withstand Voltage | I/P-O/P: 1.5kV I/P-FG: 1.5kV O/P-FG: 0.5kV 1 minute |
| Isolation Resistance | I/P-O/P I/P-FG O/P-FG: 100M Ohms/500VDC/25℃/70%RH |
| Working Temperature | -20℃~+70℃ |
| Dimension | 35×90×54.5mm |
| Weight | 0.12kg |
| Packing | / |
